15KV signatum oleum immersus Power Distribution Transformer

LiuGao venditio professio est 15KV Oleum immersum plene signatum Virtutis Distributio Transformer artifices. Nostrae dedicatio illibata ad excellentiam patet in traditione productorum summus qualitas, consuetus ad diversa requisita occurrere. Optaret Liu Gao solutiones constantes et profundam peritiam in dynamico potentiae industriae.

Mitte Inquisitionem

depictio producti

Liu Gao est 15KV Oleum immersum potentiae Distributionis Transformer Suppliers plene signatum, oleum transformatorum immersorum nostris conformibus signis IEC. Core eius scheda Pii frigidae qualitatis involuta est et cidaris non puncturae plenae structurae et gyro qualitatis.

oxygen-free copper.It cisternina de CONRUGIS shteet generis seu expansionis generis radiator adoptat.

Sicut conservatori olei non indiget, summa commutatoris olei immersi minuitur, et sicut commutator oleum cum aere non contrahit, oleum senescit retardatur, ita prolongat servitium vitae commutatoris olei immersi.

Productum hoc late in urbana potestate eget refectionem, loca residentialem, officinam, summus ortus aedificium, officinas fodiendarum, deversorium, mallum, aeroportus, ferriviaria, campus oleum, emporium, via et alia loca fori.

15KV signatum oleum immersus Power Distributio Transformer Operating Opera

1. Altissimus temperatus ambientium: + 40℃

2. temperatus ambientium Lowest: -25℃

3. Elevatio: infra 1000 metra

4. Altissimum menses mediocris relativae humiditatis: XC% (ante 20℃)

5. Locatio instruitur: apta ad institutionem in locis ab igne vel explosione discriminum immunis, inquinatio significantia, corrosio chemica, vel tremor nimia, sive intus sive foris.

15KV signatum oleum immersus Power Distribution Transformer Characteres

1. Transformator olei-immersus bonum calorem exhibet emissionem et capacitatem substantialem cultro. Potest operari sine machina venti protractum ad 130% cultro, servans plenum onus sine vento coacto sub IP45 refrigerationis conditionibus.

2. Transfigurator olei baptizati salutem perfectam et resistentiam igni praestat, quae combustionem per longum tempus in 800ºC sustinere non potest sine fumo emisso.

3. Cum valida resistentia ad concussionem thermarum, transformator olei immersus statim in -50ºC onerari potest.

4. Commutator olei-immersi notas completas waterproofing et airproofing ad augendam suam vetustatem.

5. Procurans nullam partialem missionem, transformator olei-immersus altam servat integritatem operationis.

6. Cum bona hydrophobicitate et resistentia ad ustionem alcalinam et influentiam fundamentalem, transformator olei-immersus in variis condicionibus environmentalibus certas esse probat.

7. Transformator olei immersus environmentally- amica est, sonum submissam producens, vapores nullos deleterios et facile dissolutos.

15KV signatum oleum immersus Power Distribution Transformer Specification

Technical Data of 11kV S9 Series Distribution Transformer
Rated Capacity	Circulus intentionis (kV)		Connection Methodi	Damnum (kW)		Nullus onus current	Impedimentum intentionis	Pondus (kg)			(mm)			Cange
											(mm)			Cange
											(L)	(W)	(H)
(kVA)	HV	LV		Nullus onus	Load	%	%	machina	Oleum	Crassa	Dimension			Vertical	Horizontal
5				0.07	0.35	4	4	50	45	145	550	450	800	400	350
10				0.09	0.4	3.5		70	55	185	550	450	800	400	350
20				0.11	0.52	3		110	60	235	660	505	850	400	350
30				0.13	0.63/0.6	2.3		130	65	265	660	530	870	450	340
50				0.17	0.91/0.87	2		195	80	365	740	600	930	450	380
63				0.2	1.09/1.04	1.9		230	80	400	720	620	1000	450	380
80				0.25	1.31/1.25	1.9		260	95	460	770	640	1030	450	430
100				0.29	1.58/1.5	1.8		300	95	510	820	710	970	550	450
125	11			0.34	1.89/1.8	1.7		335	115	585	1040	680	1080	550	470
160	10.5			0.4	2.31/2.2	1.6		405	130	685	1090	670	1130	550	520
200	10	0.4	Yyn0	0.48	2.73/2.6	1.5		490	150	810	1160	760	1090	550	520
250	10	0.69	Dyn11	0.56	3.2/3.05	1.4		565	170	935	1215	775	1180	650	550
315	6			0.67	3.83/3.65	1.4		655	200	1095	1345	890	1205	650	550
400	6.3			0.8	4.52/4.3	1.3		840	250	1385	1450	935	1240	650	550
500				0.96	5.41/5.15	1.2		935	235	1505	1515	970	1280	750	600
630				1.2	6.2	1.1	4.5	1100	330	1830	1595	1040	1315	850	660
800				1.4	7.5	1		1360	370	2225	1765	1170	1350	850	660
1000				1.7	10.3	1		1455	475	2555	1855	1255	1490	850	660
1250				1.95	12	0.9		1715	545	3140	1885	1270	1590	850	660
1600				2.4	14.5	0.8		2095	630	3680	1950	1620	2020	850	700
2000				2.8	19.8	0.8		2340	715	4190	2060	1740	2050	820	820
2500				3.3	23	0.7		2920	830	5100	2250	1800	2100	1070	1070
