10KV oleum immersus Power distributio Transformer

LuGao venditio professio est 10KV Olei Immersae Virtutis Distributio Transformer artifices. Nostra dedicatio illibata ad excellentiam constat in traditione productorum nobilium, nativus ad diversa requisita. Optaret Liu Gao solutiones constantes et profundam peritiam in dynamico potentiae industriae.

Mitte Inquisitionem

depictio producti

Lu Gao est 10KV Oleum immersum Power Distribution Transformer Suppliers, nostrum oleum Transformatores baptizati conformes Signis IEC. Core eius scheda Pii frigidae qualitatis involuta est et cidaris non puncturae plenae structurae et gyro qualitatis.

oxygen-free copper.It cisternina de CONRUGIS shteet generis seu expansionis generis radiator adoptat.

Sicut conservatori olei non indiget, summa commutator olei immersi minuitur, et sicut commutator oleum cum aere non contrahit, oleum senescit retardatur, ita prolongat servitium vitae commutatoris olei immersi.

Productum hoc late in urbana potestate eget refectionem, loca residentialem, officinam, summus ortus aedificium, officinas fodiendarum, deversorium, mallum, aeroportus, ferriviaria, oleum campi, emporium, via et alia loca fori.

10KV Oleum immersus Power Distributio Transformer Operating Operans

1. Altissimus temperatus ambientium: + 40℃

2. temperatus ambientium Lowest: -25℃

3. Elevatio: infra 1000 metra

4. Altissimum menses mediocris relativae humiditatis: XC% (ante 20℃)

5. Locatio instruitur: apta ad institutionem in locis ab igne vel explosione discriminum immunis, inquinatio significantia, corrosio chemica, vel tremor nimia, sive intus sive foris.

10KV Oleum immersus Power Distribution Transformer Characteres

1. Transformator olei-immersus bonum calorem exhibet emissionem et capacitatem substantialem cultro. Potest operari sine machina venti protractum ad 130% onerare, servans plenum onus sine vento coacto sub IP45 refrigerationis conditionibus.

2. Transformator olei-immersus salutem perfectam et resistentiam igni praestat, quae combustionem per longum tempus in 800ºC sustinere non potest sine fumo emisso.

3. Cum valida resistentia ad concussionem thermarum, transformator olei immersus statim in -50ºC onerari potest.

4. Commutator olei-immersi notas completas waterproofing et airproofing ad suam vetustatem augendam.

5. Procurans nullam partialem missionem, transformator olei-immersus altam servat integritatem operationis.

6. Cum bona hydrophobicitate et resistentia ad ustionem alcalini et influentiam fundamentalem, transformator olei baptizati in diversis condicionibus environmental certissimus esse convincit.

7. Transformator olei immersus environmentally- amica est, sonum submissam producens, vapores nullos deleterios et facile dissolutos.

10KV Oleum immersus Power Distribution Transformer Specification

Technical Data of 10kV S11, S11-M Series Distribution Transformer
Rated Capacity	Circulus intentionis (kV)		Connection Methodi	Damnum (kW)		Nullus onus current	Impedimentum intentionis	Pondus (kg)			(mm)			Cange
											(mm)			Cange
											(L)	(W)	(H)
(kVA)	HV	LV		Nullus onus	Load	%	%	Machina	Oleum	Crassa	Dimension			Vertical	Horizontal
10				0.065	0.4	3.5		90	55	220	650	450	880	400	350
20				0.08	0.52	3		140	60	270	720	490	950	400	350
30				0.1	0.63/0.6	2.3		185	70	330	750	490	970	450	340
50				0.13	0.91/0.87	2		260	80	430	770	550	1030	450	380
63				0.15	1.09/1.04	1.9		260	85	440	800	600	1040	450	380
80				0.18	1.31/1.25	1.9		320	95	520	790	600	1070	450	430
100				0.2	1.58/1.5	1.8		355	100	570	830	640	1050	550	450
125	11			0.24	1.89/1.8	1.7		425	115	675	1070	700	1150	550	470
160	10.5			0.28	2.31/2.2	1.6		510	130	790	1120	700	1220	550	520
200	10	0.4	Yyn0	0.34	2.73/2.6	1.5		550	145	850	1080	690	1160	550	520
250	6	0.69	Dyn11	0.4	3.2/3.05	1.4		630	165	985	1160	740	1190	650	550
315	6.3			0.48	3.83/3.65	1.4		755	190	1155	1230	800	1240	650	550
400				0.57	4.52/4.3	1.3		910	225	1405	1310	860	1250	650	550
500				0.68	5.41/5.15	1.2		1050	240	1600	1370	890	1350	750	600
630				0.81	6.2	1.1	4.5	1250	310	1945	1580	1060	1310	850	660
800				0.96	7.5	1		1540	365	2350	1640	1060	1500	850	660
1000				1.15	10.3	1		1690	405	2645	1720	1160	1540	850	660
1250				1.36	12	0.9		1965	560	3230	1790	1160	1740	850	660
1600				1.64	14.5	0.8		2355	650	3805	1830	1190	1850	850	700
2000				1.96	19.8	0.8		2570	615	4245	2190	1900	1950	820	820
2500				2.31	23	0.7		3130	810	5280	2180	1940	2250	1070	1070
